CNC Spring Coiling Machine

HCT-680

Φ3.0-8.0mm High Speed Spring Coiling Machine

	Φ3.0-8.0mm Wire Diameter
	6 Axis with External Spring Length Gage Optional
	Taiwan Hust Controller&Japan Servo Motor
	High Precision&Strong Stability
	Fast Response After-sales Service Team

Inquiry Download catalog

Number Of Axis6 axis

Wire Size RangeΦ3.0-8.0 mm

Max. Outside DiameterΦ120 mm

Max. Pitch Of Spring100 mm

Max. Feeding Speed60 m/min

Spring Index4

Feeding Roller Pairs4 pairs

Feeding Motor30.0 kw

Upper Cutter Motor7.5 kw

Under Cutter Motor7.5 kw

Cam Motor2.7 kw*2

Pitch Motor2.7 kw

Dimension(LxWxH)2000x2100x2200 mm

Weight6000 kgs
